Step by Step Guide to Fix Windows Stop Code 0x0000003C

0x0000003C Error: Windows triggered an alignment check exception

Try it yourself, or Reach Out!

If you still need a hand, we’re just a plan away

What is 0x0000003C Error?


The Windows Stop Code 0x0000003C, labelled ALIGNMENT_CHECK, is a Blue Screen of Death (BSOD) that appears when the processor detects a data alignment fault during a privileged or kernel-mode instruction. This happens when the system attempts to access misaligned memory addresses, which certain CPU architectures and drivers cannot tolerate. Although rare in modern systems, this error can occur in high-security environments, miscompiled software environments, or when specific processor features like alignment checking are enabled in BIOS or kernel mode.

Causes

  • Faulty or Misbehaving Drivers: Low-level device drivers with improper memory alignment routines can cause the CPU to halt and issue an alignment fault exception.
  • Hardware or CPU Feature Conflicts: Certain processors with strict alignment enforcement may trigger errors when interacting with legacy or poorly written software.
  • Misconfigured BIOS Settings: Enabled alignment check flags or virtualisation settings may expose memory access violations in kernel execution.
  • Faulty RAM or Storage Medium: Unstable memory modules or bad sectors may result in invalid instruction fetches or misaligned data reads.
  • Software Debugging Tools or Custom Builds: Debug-mode OS configurations or developer kernels may enforce stricter alignment rules and cause this BSOD.
  • Corrupted System Files or Libraries: Key system components involved in memory operations may cause illegal access patterns leading to crashes.

Resolution Steps




1. Update or Roll Back Device Drivers

  • Press Win + X → Open Device Manager.
  • Look for recently added or updated drivers, especially storage, graphics, or custom kernel-level drivers.
  • Right-click → Update Driver or Roll Back Driver.

2. Run System File Checker and DISM

  • Open Command Prompt as Administrator, then run:
  • sfc /scannow
  • Then run:
  • DISM /Online /Cleanup-Image /RestoreHealth
  • These commands verify and restore corrupted system files that may cause alignment exceptions.

3. Disable Alignment Checking in BIOS

  • Enter BIOS/UEFI setup during boot (usually via Del or F2).
  • Look for CPU features or virtualisation settings like “Alignment Check” or “Memory Remapping.”
  • Disable such options (if enabled) and save the configuration.

4. Uninstall Debug Tools and Development Builds

  • Go to Control Panel → Programs and Features.
  • Remove any custom Windows builds, debuggers, kernel tracing tools, or development SDKs.
  • Reboot the system after cleaning up the software environment.

5. Perform Clean Boot

  • Press Win + R → Type msconfig → Enter.
  • Under Services tab → Check Hide all Microsoft services → Click Disable all.
  • Go to Startup → Open Task Manager → Disable all startup items.
  • Reboot to eliminate low-level software conflicts.

6. Run Memory Diagnostics

  • Press Win + R → Type mdsched.exe and hit Enter.
  • Choose Restart now and check for problems.
  • Allow the system to perform a full RAM check and observe results.

7. Update BIOS and Chipset Drivers

  • Visit your motherboard/computer manufacturer’s website.
  • Download and install the latest BIOS and chipset updates.
  • These often address CPU compatibility and memory access issues.

8. Perform System Restore

If the BSOD started recently:

  • Go to Control Panel → Recovery → Open System Restore.
  • Choose a restore point from before the issue began.
  • Follow the on-screen instructions to complete the rollback.
