Green Cloud Architecture
In the Green Cloud architecture, users submit their Cloud service requests through a new middleware Green Broker that manages the selection of the greenest Cloud provider to serve the user’s request. A user service request can be of three types i.e., software, platform or infrastructure. The Cloud providers can register their services in the form of „green offers‟ to a public directory, which is accessed by Green Broker. The green offers consist of green services, pricing and time when it should be accessed for least carbon emission. Green Broker gets the current status of energy parameters for using various Cloud services from Carbon Emission Directory. The Carbon Emission Directory maintains all the data related to energy efficiency of Cloud service. This data may include PUE and cooling efficiency of Cloud datacenter, which is providing the service, the network cost and carbon emission rate of electricity, Green Broker calculates the carbon emission of all the Cloud providers who are offering the requested Cloud service. Then, it selects the set of services that will result in least carbon emission and buy these services on behalf users.
The Green Cloud framework is designed such that it keeps track of overall energy usage of serving a user request. It relies on two main components, Carbon Emission Directory and Green Cloud offers, which keep track of energy efficiency of each Cloud provider and also give incentive to Cloud providers to make their service “Green”. From user side, the Green Broker plays a crucial role in monitoring and selecting the Cloud services based on the user QoS requirements, and ensuring minimum carbon emission for serving a user. In general, a user can use Cloud to access any of these three types of services (SaaS, PaaS, and IaaS), and therefore process of serving them should also be energy efficient. In other words, from the Cloud provider side, each Cloud layer needs to be “Green” conscious.
